Porcelain-Enameled Upswept Cooktop
Sealed Cooktop Burner .
Helps contain spills from dripping beneath cooktop for easy clean-up. Sealed gas burner controls let you adjust flame height for various cooking needs.
Edge-to-Edge
Enjoy the convenience of a larger cooking surface and easy cleaning with the GE edge-to-edge cooktop
Big View Oven Door
The Big View Window provides the convenience of easy viewing of all of the oven's contents without opening the door and allowing valuable heat to escape.
Electronic Oven Controls.
Electronic pads on the control panel are easy to operate with just a touch
Oven Interior Light.
Allows you to check on and view your meal with ease as it cooks
Steam Clean
Fill the reservoir with water and set your oven to "Steam Clean". After 30 minutes you're able to wipe clean all grime and residue.
| Weights & Dimensions | |
|---|---|
| Interior Dimensions - Upper Oven (w x h x d) (in.) | 24 x 18-1/2 x 19 |
| Height to Cooking Surface (in.) | 36 1/4 +/-1/4 |
| Depth With Oven Door Open 90 Degrees (in.) | 46 1/4 |
| Cabinet Width Required (in.) | 30 |
| Approximate Shipping Weight (lbs.) | 172 |
| Warranty | |
| Limited 1-year | Entire Appliance; In Home; Parts & Labour |
| Power & Ratings | |
| Volts; Hertz; Amps | 120V; 60Hz; 5A |
| Oven/Broiler BTU Rating - Nat. Gas (000's BTU's) | 18.0 |
| Oven/Broiler BTU Rating - LP (000's BTU's) | 16.0 |
| Inputs & Outputs | |
| Cleaning Type | Steam Clean |
| Slide - Out Broiler Drawer | Yes |
| Oven Racks | 2 Nickel |
| Oven Interior Light | Yes |
| One-Piece Upswept Cooktop | Yes |
| Ignition System | Electronic |
| Hi / Low Broil | Yes |
| Griddle | Integrated Non-Stick |
| Electronic Clock & Timer | Yes |
| Fuel Type | Gas |
| Edge-to-Edge Cooktop | Yes |
| Cooktop | Porcelain-Enameled Upswept |
| Cooktop Burners | 4 Sealed Burners |
| Control Lock Capability | Yes |
| Certified Sabbath Mode | Yes |
| Control Location | Front |
| Center Oval Burner | (1) 10,000 BTU |
| Burner Grate Type / Style | Continuous Black Heavy Cast |
| Burner - Right Rear | 12,000 BTU |
| Burner - Right Front | 9,500 BTU |
| Burner - Left Front | 15,000 BTU |
| Burner - Left Rear | 5,000 BTU Precise Simmer |
| Broiler Drawer | Yes |
| Auto Oven Shut-Off With Override | Yes |
| Capacity | |
| Capacity | 5.0 |
| Inputs & Outputs | |
| Audible pre-heat signal | Yes |
| Capacity | |
| Extra Large Oven | Yes |
| Appearance | |
| Oven Door with Window | Big View |
| Scratch-Resistant Backguard | Porcelain-Enameled |
| Knob Colour | Stainless Steel Appearance |
| Handle Style | Designer Style (colour matched) |
| Handle Style | Stainless Steel |
| Frameless Lift-off Oven Door | Black Glass |
| Cooktop Grate/Burner Cap Colour | Glossy Black |
| Colour Appearance | Stainless Steel |
| Cavity Colour | Grey |
| 4 Leveling Legs | Yes |
| Accessories | |
| LP Conversion Kit | Included |
| Weights & Dimensions | |
| Overall Depth (excluding handle) | 26-1/4 |
| Overall Depth (in.) | 28-3/4 |
| Overall Height (in.) | 46-1/4 |
| Overall Width (in.) | 30 |
