- LED Downlighting - hidden descretely above the control panel provides functional and stylish illumination
- Patented Pedestal Star® Burner with QuickClean Base® designed for easy surface cleaning and superior heat spread for any size pan
- Precision simmering capabilities as low as 100°F (375 BTU) with 2 ExtraLow® Simmer burners
- Five Star® Burners with an overall output of 59,000 BTUs (NG)
- Star-K certified
INNOVATION
- Exclusive, patented Star® Burner – most even heating, unsurpassed flame coverage
- Can be installed with zero inch clearance, flush against rear wall surface
- Precision simmering capabilities as low as 100°F (375 BTU) with 2 ExtraLow® Simmer burners
- QuickClean Base® designed for easy surface cleaning
PERFORMANCE
- Professional style, continuous cast iron grates
- Continuous porcelain, easy to clean cooking surface
- Five burner Rangetop with an overall output of 59,000 BTU's (NG)
- Widest range of simmer options from 375 BTU to 3,000 BTU
- Star® design delivers superior heat spread for any size pan
- Simmer without stirring/scorching with exclusive ExtraLow®
DESIGN
- Bold Professional design
- Patented Pedestal Star® Burner with QuickClean Base®
- Restaurant style metal knobs
- Signature blue indicator lighting
- Island trim shipped standard with rangetop
| Cooking zone 9 | |
|---|---|
| Location of 9th heating element | front centre/cent |
| Cooking zone 8 | |
| Location of 8th heating element | front middle / central |
| Cooking zone 7 | |
| Type of 7th heating element | Gas |
| Location of 7th heating element | front right |
| Cooking zone 6 | |
| Location of 6th heating element | center right |
| Cooking zone 5 | |
| Type of 5th heating element | Gas |
| Location of 5th heating element | back right |
| Cooking zone 4 | |
| Location of 4th heating element | middle back |
| Cooking zone 3 | |
| Type of 3rd heating element | Gas |
| Location of 3rd heating element | back left |
| Cooking zone 2 | |
| Location of 2nd heating element | center left |
| Cooking zone 1 | |
| Type of heating element | Gas |
| Location of 1st heating element | front left |
| Size and Weight | |
| Net weight (kg) | 63.338 kg |
| Overall appliance dimensions (HxWxD) (mm) | 268.3 x 760 x 656 mm |
| Construction type | |
| Number of electric warming zones | 0 |
| Number of radiant elements | 0 |
| Type of grate | Cast iron |
| Installation Type | Built-in |
| Number of halogen elements | 0 |
| Number of gas burners | 4 |
| Type of frame | Professional, Standard frame |
| Number of electric cooking zones | 0 |
| Number of electric elements | 0 |
| Installation type | Built-in |
| Color of surface | Stainless steel |
| Color of frame | Stainless steel |
| General | |
| Safety device | automatic reignition |
| Control Type | sword knobs |
| Heating Technology | Gas |
| Cooking zone 9 | |
| Type of 9th heating element | Gas |
| Safety | |
| Type of safety device for gas | Without |
| Power on indicator | Yes |
| Residual heat indicator | without |
| Safety device | automatic reignition |
| Main on/off switch | - |
| Connection | |
| Power cord length (cm) | 244 cm |
| Heating Technology | Gas |
| Frequency (Hz) | 60 Hz |
| Location of gas connection | bottom, rear, right |
| Gas connection rating (W) | 17,300 W |
